Ravin Integrated Xero X1i Crossbow Scope

(No reviews yet) Write a Review
Adding to cart… The item has been added

Target something greater from two apex leaders in crossbow accuracy. The Ravin® integrated Xero® X1i Crossbow Scope is customized exclusively for Ravin from Garmin®, and optimized for your Ravin crossbow model. Sighting in the Xero X1i scope is quick, easy, and automatic. Simply mount the scope, select your Ravin model, and sight-in at 20 yards— the precise digital aimpoints are pre-calibrated. Garmin Xero X1i’s advanced processor does the rest. It’s a fusion of accuracy unlike anything the world has seen. This high-performance upgrade increases deadly accuracy and eliminates the need for a rangefinder, saving precious ounces and unnecessary gear.

The X1i is preloaded with the ballistics for every model ever made by Ravin except the R18: R9/R10/R15/R20/R26/R29/R5X/R10X/R26X/R29X/R500.


Xero X1i crossbow scope
Wired standard length range finder trigger
Lens covers
microUSB cable
2 AAA lithium batteries

Unit dimensions (LxWxH): 6.2 x 2.6 x 3.7 (158 x 66 x 95 mm)
Weight: 1.9 lbs (862 g)
Multi-color display: yes
Objective diameter: 1.2" (32 mm) diagonal
Magnification: 3.5x
Field of view: 5 degrees
Eye relief: 2.4" (62 mm)
Focus adjustment: +/- 2 diopters
Range to game targets: 250 yds (229 m)
Range to reflective targets: 500+ yds (457+ m)
Battery life: Up to 1 year
Battery type: 2 AAA lithium batteries (included)
Operating temperature range: -20 C to 60 C (-4 F to 140 F)
Water rating: IPX71, Nitrogen filled
Interface: microUSB
Connectivity: ANT®
AutoCal: Bow speeds up to 650 FPS, out to 150 yrds
Laser Locate™: yes (with compatible Garmin wearables and handhelds)
Electronic level: yes
Compass: yes
Angle compensated distance: yes
Aiming accuracy: 1/2 MOA (1/2" at 100 yds)
aFlight Apex: yes
Auto brightness: yes
Steady aim: yes
Configurable aim point shapes: yes
Dual rangefinder triggers: yes
Shot counter: yes
Integrated mount: yes
Roll at shot: yes
Impulse duration: yes
Auto color option: yes (pick color preference for bright and dim conditions separately)


All our products are brand new and include the manufacturer’s warranty. Details on this warranty can be found on the manufacturer's website. Additional information on Wyvern Creations policies and shipping information can be found in the Shipping/Policies link at the top of the page. Please review this and the manufacturer’s warranty prior to purchase.
